"Use your timing light and verify the timing is correct. The timing mark should land on 20°.
If not, we need to change the Trigger Angle."
Is this a misprint? It should say 10 degrees ( cant find the button sorry)
Later you say to adjust till it says 10?
Thanks almost finished with the assembly. I could not have done it with out this write up!
If not, we need to change the Trigger Angle."
Is this a misprint? It should say 10 degrees ( cant find the button sorry)
Later you say to adjust till it says 10?
Thanks almost finished with the assembly. I could not have done it with out this write up!
01-19-2012, 08:53 AM
#25
it's really not hard. Say you have a '91.
Instead of wiring 1Q (the a/c switch) to Input 1 IN then back OUT to 1J, simply completeing a circuit.
You'd wiring 1Q to Input 1 IN, The input 1 OUT to PE1.
Then from PAO to 1J.
Now, when the A/C switch is grounded, the MS knows, it can bump up the idle, then ground the output to 1J.
The only issue with it is that you quickly run out of inputs and outputs. Especially on a 99 running seq. injection.
----
If you want to run launch control, you'd do something similar, where you'd take the clutch switch (1V?) to Input 2 IN, then Input 2 OUT, to FLEX.
----
Adding seq. injection is extremely easy--you have the option for the module from diyautotune.com, or you can build the circuit yourself using (2) VND5N07s, (2) 100K resistors, and (2) 1K resistors.
I can post the circuit later.
But PT6 and Pt7 become the inputs for channels 3 and 4 respectivally. Then the drivers go out to the harness. Since we inject in a firing order of 1342, You need ot make sure you wire to the correct clyinders, where:
INJ1 = Clyinder #1
INJ2 = Clyinder #3
INJ3 = Clyinder #4
INJ4 = Clyinder #2
the 1.6L miata requires you to run to extra wires out your db15 and into the engine bay, and rework the injector harness to make sure each injector is run on it's own channel. All other 1.8L miatas are pre-wired for seq. injection.
Instead of wiring 1Q (the a/c switch) to Input 1 IN then back OUT to 1J, simply completeing a circuit.
You'd wiring 1Q to Input 1 IN, The input 1 OUT to PE1.
Then from PAO to 1J.
Now, when the A/C switch is grounded, the MS knows, it can bump up the idle, then ground the output to 1J.
The only issue with it is that you quickly run out of inputs and outputs. Especially on a 99 running seq. injection.
----
If you want to run launch control, you'd do something similar, where you'd take the clutch switch (1V?) to Input 2 IN, then Input 2 OUT, to FLEX.
----
Adding seq. injection is extremely easy--you have the option for the module from diyautotune.com, or you can build the circuit yourself using (2) VND5N07s, (2) 100K resistors, and (2) 1K resistors.
I can post the circuit later.
But PT6 and Pt7 become the inputs for channels 3 and 4 respectivally. Then the drivers go out to the harness. Since we inject in a firing order of 1342, You need ot make sure you wire to the correct clyinders, where:
INJ1 = Clyinder #1
INJ2 = Clyinder #3
INJ3 = Clyinder #4
INJ4 = Clyinder #2
the 1.6L miata requires you to run to extra wires out your db15 and into the engine bay, and rework the injector harness to make sure each injector is run on it's own channel. All other 1.8L miatas are pre-wired for seq. injection.
